Explore CNC turning, milling, five-axis and production systems using verified GKD product data.
LM-10SY-III
LM10SY-III Double/dual spindles CNC Turret Lathe Machine With Y Axis
LM10SY-III Double spindles CNC Turret Lathe Machine With Y AxisModelLM-10SY-IIIDouble spindle/Double power turretsNumber of axis10 Axis(X+Z+Y+X1+Y1+Z1+C1+C2+TD+D2)Max turning diameter on the bedФ450mmMax processing length400mmMax processing diameterФ300mmMain spindle nose ANSI A2-6Main spindle holeФ82mmBar hole diameterФ70mmMain spindle speed1-4500rpmMain spindle Chuck size8”(Hydraulic chuck)Sub-spindle noseANSI A2-4Sub-spindle holeФ46mmBar hole diameterФ36mmSub-spindle speed1-5000rpmSub-spindle chuck size6”(Hydraulic chuck)Main Spindle power11KWSub-spindle power11KWX1/X2 axis power3.1KWY1/Y2 axis power3.1KWZ1/Z2 axis power3.1KWTD axis power(milling axis)3.1KWD2 Axis2.4KWHydraulic pump motor power2.2KWCooling pump motor power1.5KWTool turret position12pcsTurret modelBMT55Turret Outer diameter shank25mmTurret Inside diameter shank(Boring tool)Ф32mmSlider Outer diameter shank20mmSlider Inside diameter shankФ20mmTD axis live tools milling speed0-4000rpmEnd milling tool specification4*ER20X1/X2/Y1/Y2/Z1/Z2 axis rapid speed25m/minX1/X2 axis travel560mm/590mmY1/Y2 axis travel150mm/150mmZ1/Z2 axis travel540mm/330mmSpindle indexing repeat positioning accuracy±0.005°Spindle indexing positioning accuracy±0.002°X/Y/Z/Z1 axis repeatability position accuracy0.003mmX/Y/Z/Z1 axis position accuracy0.002mmOil tank capacity60LCooling tank capacity95LMachine weight5800KGMachine size2600*2200*2250mmControllerSyntec 200TB
View machine
GD-15Y/3000
3000mm box way cutting length 12 stations with tailstock cnc turning lathe center
ModelGD-15Y/3000Double spindles/single power turretMax turning diameter on the bedФ920mmMax processing length3000mmMax processing diameter(Disk type)Ф630mmMax processing diameter(Cylindrical type)Ф630mmMain spindle nose A2-15(15”)Main spindle holeФ147mmBar hole diameterФ135mmMain spindle speed1800rpmMain Spindle power37KWX/Z torque30 NmTool turret position(BMT65)12pcsTurret modelBMT65Tool size32x32mmBoring tool size50mmDriven head sizeER40mmLiving tools milling speed4000rpmAxis rapid speed12m/minX axis travel325mmY axis travel±60mmZ axis travel3300mmProcessing accuracyIT6Repeatability position accuracyX ：≤0.003、Z：≤0.005Position accuracyX ：≤0.008、Z：≤0.01Tailstock travel3000mmTailstock typeMT#6Sleeve diameter150mmSleeve travel150mmMachine weight13000KGMachine size6700*2400*2400mmControllerFanuc Oi-TF
View machine
HD-600Y/1500
1500mm box way cutting length CNC turning lathe center HD-600Y/1500
ModelHD-600Y/1500Max turning diameter on the bedФ920mmMax processing length1500mmMax processing diameterФ600mmMain spindle noseA2-8(10”)Main spindle holeФ86mmBar hole diameterФ75mmMain spindle speed2800rpmMain Spindle power18.5KWDriven head power2.7KwX/Z torque30 NmTool turret position12pcsTurret modelBMT65Tool size32x32mmBoring tool size50mmDriven head sizeER32mmLiving tools milling speed4000rpmAxis rapid speed12m/minX axis travel325mmY axis travel±60mmZ axis travel1500mmTailstock travel1500mmTailstock sleeve diameter100mmTailstock sleeve travel80mmTailstock typeMT#5Processing accuracyIT6Repeatability position accuracyX ： ≤0.003 、Z1/Z2： ≤0.005Position accuracyX ： ≤0.008 、Z1/Z2： ≤0.01Machine weight10500KGMachine size6100*2200*2200mmControllerFanuc Oi-TF
View machine
