CNC turning lathe

CNC-TURNING-LATHE-CNC-52D

contact
  • SPECIFICATION
  • SUMMARY DETAILS
  • VIDEOS
  • Model

    GKD-CNC52D

    Spindle nose type

    A2-6

    Spindle hole diameter (mm)

    66

    Bar through dia (mm)

    52

    Spindle rod size (mm)

    530

    Spindle center to ground distance (mm)

    1080

    Barrel chuck

    CL-52A6

    Chuck size

    8 inch

    Controller

    Fanuc Oi-TF Plus

    X servo motor power (KW)

    2.0

    Z servo motor power (KW)

    2.0

    Maximum bed rotation diameter (mm)

    500

    Max processing length (mm)

    300

    Spindle speed (rpm)

    0-4500

    X/Z axis rapid feeding (m/min)

    ≤25

    X/Z axis positioning accuracy (mm)

    0.002

    X/Z axis repeat position accuracy (mm)

    0.003

    X axis travel (mm)

    760

    Z axis travel (mm)

    380

    Number of turret (pcs)

    12

    Spindle power (KW)

    11

    X axis power (KW)

    2.0

    Z axis power (KW)

    2.0

    Cutting pump power (KW)

    0.37

    Cutting pressure (Bar)

    1.85

    Cutting water tank capacity (L)

    95

    Tank volume (L)

    125

    Machine size (mm)

    L2029*W1700*H1922

    Machine weight (KG)

    2900
