Technical data
Specifications
Model
VMC855
X-axis travel (mm)
800
Y-axis travel (mm)
550
Z axis travel (mm)
550
Spindle nose to the table (mm)
135-685
Spindle Center to Column Guideway (mm)
590
Guide width X/Y/Z (mm)
35
Screw diameter (mm)
40
Screw Pitch (mm)
16
Workbench area (mm)
1000x550
Maximum load (kg)
500
T-slot (size x spacing) (mm)
18×90
Three-axis fast-moving speed (m/min)
48/48/36
Cutting feed rate (mm/min)
1-10000
Spindle speed (r.p.m)
8000-10000
Spindle type
BT40/BBT40
Spindle motor power (KW)
7.5
Controller
Mitsubishi
Three-axis motor power (KW)
2.0/2.0/3.0
positioning accuracy (mm)
±0.005/300
Repeatability positioning accuracy (mm)
±0.003/300
Tool magazine type (pcs)
24 ATC
Tool change time (s)
1.2
Max tool weight (kg)
8
Machine weight (kg)
5270
Machine size (mm)
2700x2300x2550
